Plastica Belgravia Wooden Above Ground Swimming Pool

The Plastica Belgravia Wooden Above Ground Swimming Pool measures 3.694m x 5.564m internally and has a 'stretched octagonal' design.

With plenty of space to accommodate the family and for the more serious swimmers, the Plastica Belgravia pool comes complete with everything needed to install and maintain the pool plus iFlo Filtration Kit.

Please note all Plastica wooden pools are made to order and are currently on an approx. 22 working days lead time.
**Additional delivery charges may be applicable for this product. Please see tab below for further information.**
What Swimming Pool Approved and Spata Approved

Was:

£9,500.00

Now

£8,459.00

*
Brochure Request

The Plastica Belgravia Wooden Above Ground Swimming Pool has a very spacious interior, ideal for families and keen swimmers.  Complete with interior and exterior ladders,  Structure Kit, Maintenance Kit and Plain Liner with a number of optional extras to create your perfect home above ground swimming pool.


External Dimensions: 6.082m x 4.212m

Internal Dimensions: 5.564m x 3.695m x 1.312m

Concrete Base Dimensions: 6.252m x 4.382m x 0.150mm

Water Depth: 1.143m

Water Volume: 4600 Gallons / 21000 Litres


Each Plastica Wooden Above Ground Swimming Pool is supplied as a complete kit, including:


Structure Kit:

  • A robust timber structure using 44mm pressure treated redwood timber from renewable sources
  • All timber supports and fixings
  • External wooden ladder and internal stainless steel ladder
  • Exotic 2 piece hardwood top shelving featuring a reversable profile, designed to make fixings as neat as possible using plug and pellet hidden fixings
  • Metal braces which are boxed in to keep the wonerful timber aesthetics
  • Foam and felt underlay - Giving liners a beautifu soft touch as weel as added protection. Includes spray adhesive and underlay tape
  • White goods kit - Wide mouth skimmer, return and low level suction where appropriate


Filtration Kit:

  • Reliable iflo 0.75hp pump and filter package
  • Essential plumbing kit includes:
  • 5 x 1.5’’ 45 degree Elbows - White

  • 1 x Pack of 10 1.5’’ 90 degree Elbows - White

  • 1 x Pack of 8 1.5’’ Class C Pipe 1.5m length


Plain Liner included
with the option to upgrade to include a Mosaic Tile Band or Fully Patterned liner


Maintenance Kit:

  • Backwash hose
  • Chemical starter kit
  • Vacuum head & hose
  • Telescopic pole
  • Leaf net and brush
  • Everything you need to keep your pool beautifully clean



Counter-Current System

The optional SwimMasterTM counter current unit has a 316 stainless steel construction and has been specifically chosen to complement Plastica’s range of Premium wooden pools. Its sleek,minimalist design means it can be situated perfectly into their wooden pools. Coupled to the Nadorself 3hp jet pump, this unit is capable of flowing up to 60m3/hr. Warranty information: 2 Years, 1 Year pump seal.

For choice of patterns and colours please see brochure tab. All Swim offer free advice and guidance at every stage of choosing and installing your new swimming pool, please get in touch with us on 02920 705059 or via our enquiry form.

Overview

The Plastica Belgravia Wooden Above Ground Swimming Pool has a very spacious interior, ideal for families and keen swimmers.  Complete with interior and exterior ladders,  Structure Kit, Maintenance Kit and Plain Liner with a number of optional extras to create your perfect home above ground swimming pool.


External Dimensions: 6.082m x 4.212m

Internal Dimensions: 5.564m x 3.695m x 1.312m

Concrete Base Dimensions: 6.252m x 4.382m x 0.150mm

Water Depth: 1.143m

Water Volume: 4600 Gallons / 21000 Litres


Each Plastica Wooden Above Ground Swimming Pool is supplied as a complete kit, including:


Structure Kit:

  • A robust timber structure using 44mm pressure treated redwood timber from renewable sources
  • All timber supports and fixings
  • External wooden ladder and internal stainless steel ladder
  • Exotic 2 piece hardwood top shelving featuring a reversable profile, designed to make fixings as neat as possible using plug and pellet hidden fixings
  • Metal braces which are boxed in to keep the wonerful timber aesthetics
  • Foam and felt underlay - Giving liners a beautifu soft touch as weel as added protection. Includes spray adhesive and underlay tape
  • White goods kit - Wide mouth skimmer, return and low level suction where appropriate


Filtration Kit:

  • Reliable iflo 0.75hp pump and filter package
  • Essential plumbing kit includes:
  • 5 x 1.5’’ 45 degree Elbows - White

  • 1 x Pack of 10 1.5’’ 90 degree Elbows - White

  • 1 x Pack of 8 1.5’’ Class C Pipe 1.5m length


Plain Liner included
with the option to upgrade to include a Mosaic Tile Band or Fully Patterned liner


Maintenance Kit:

  • Backwash hose
  • Chemical starter kit
  • Vacuum head & hose
  • Telescopic pole
  • Leaf net and brush
  • Everything you need to keep your pool beautifully clean



Counter-Current System

The optional SwimMasterTM counter current unit has a 316 stainless steel construction and has been specifically chosen to complement Plastica’s range of Premium wooden pools. Its sleek,minimalist design means it can be situated perfectly into their wooden pools. Coupled to the Nadorself 3hp jet pump, this unit is capable of flowing up to 60m3/hr. Warranty information: 2 Years, 1 Year pump seal.

For choice of patterns and colours please see brochure tab. All Swim offer free advice and guidance at every stage of choosing and installing your new swimming pool, please get in touch with us on 02920 705059 or via our enquiry form.

Installation Video
Wooden Pool Delivery Charges

Brochures
Useful Documents
